Telemecanique Sensors
Telemecanique Sensors - 9007TUD4M12
Telemecanique Sensors - 9007TUD4M12
SKU:9007TUD4M12
Normaler Preis
€417,53 EUR
Normaler Preis
Verkaufspreis
€417,53 EUR
Stückpreis
/
pro
Versand wird beim Checkout berechnet
Verfügbarkeit für Abholungen konnte nicht geladen werden
Limit switch, 9007, 600 VAC 12amp t +options
Technische Daten
| Hauptmerkmale | |
|---|---|
| Series name | Severe duty |
| Device application | Heavy duty standard mill switch universal mill switch |
| Device short name | T |
| Head type | Rotary head |
| Ergänzende Merkmale | |
| Base plate style | Style D |
| Body material | Cast zinc |
| Switch actuation | CW and CCW |
| Electrical connection | Screw clamp terminal AWG 22...AWG 12 |
| Cable entry | 1 entry for Pg 13.5 conforming to UL 508 |
| Switch function | SPDT-DB |
| Contact operation | Snap action |
| Contact form | Form Z |
| Contacts material | Silver flashed copper |
| Contact status | Closed A for CCW position, open A for CW position, open B for CCW position, closed B for CW position |
| Positive opening | Without |
| Type of operator | Spring return lever arm, spring return to be ordered separately |
| Repeat accuracy | +/- 0.004 in 0.1 mm |
| Contact code designation | A600, Q600 |
| Umgebung | |
| Product certifications | CE CSA UL listed |
| Shock resistance | 30 gn |
| Vibration resistance | 10 gn (f= 10-55 Hz) |
| NEMA degree of protection | NEMA 1/2/4/12/13 |
| IP degree of protection | IP65, IP66, IP67 |
| Electrical shock protection class | Class 0 |
| Protective treatment | Corrosion resistant gray paint |
Verpackungseinheiten
| Unit type of package 1 | PCE |
| Number of units in package 1 | 1 |
| Package 1 height | 17.742 CENTIMETER |
| Package 1 width | 6.985 CENTIMETER |
| Package 1 length | 45.064 CENTIMETER |
| Package 1 weight | 1.134 KILOGRAM |
| Indivisible sale quantity | 1 |
