Telemecanique Sensors
Telemecanique Sensors - XCKJ1656474001
Telemecanique Sensors - XCKJ1656474001
SKU:XCKJ1656474001
Normaler Preis
€148,68 EUR
Normaler Preis
Verkaufspreis
€148,68 EUR
Stückpreis
/
pro
Versand wird beim Checkout berechnet
Verfügbarkeit für Abholungen konnte nicht geladen werden
Limit switch, XC Standard, XCKJ, steel roller plunger reinforced, 600 V AC, 10 A
Technische Daten
| Hauptmerkmale | |
|---|---|
| Range of product | Telemecanique Limit switches XC Standard |
| Device short name | XCKJ |
| Product or component type | Limit switch |
| Series name | Standard format |
| Material | Metal |
| Fixing mode | By the body |
| Overvoltage category | Class I conforming to IEC 61140, class I conforming to NF C 20-030 |
| Contact operation | Snap action |
| Body material | Zamak |
| Head material | Zamak |
| IP degree of protection | IP66 conforming to IEC 60529 |
| Contacts insulation form | Zb |
| Ergänzende Merkmale | |
| Product certifications | CCC CSA UL |
| Standards | CENELEC EN 50041 CSA C22.2 No 14 IEC 60204-1 IEC 60947-5-1 UL 508 |
| Vibration resistance | 25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3 |
| Terminals description ISO n°1 | (11-12)NC (13-14)NO |
| Shock resistance | 50 gn for 11 ms conforming to IEC 60068-2-27 |
| Compatibility code | XCKJ |
| Umgebung | |
| Protective treatment | TH |
| IK degree of protection | IK07 conforming to IEC 62262 |
Verpackungseinheiten
| Unit type of package 1 | PCE |
| Number of units in package 1 | 1 |
| Package 1 height | 5.2 CENTIMETER |
| Package 1 width | 5.8 CENTIMETER |
| Package 1 length | 19.1 CENTIMETER |
| Package 1 weight | 0.42 KILOGRAM |
| Unit type of package 2 | S01 |
| Number of units in package 2 | 9 |
| Package 2 height | 15 CENTIMETER |
| Package 2 width | 40 CENTIMETER |
| Package 2 length | 15 CENTIMETER |
| Package 2 weight | 4.691 KILOGRAM |
| Unit type of package 3 | P06 |
| Number of units in package 3 | 288 |
| Package 3 height | 76 CENTIMETER |
| Package 3 width | 80 CENTIMETER |
| Package 3 length | 60 CENTIMETER |
| Package 3 weight | 160.027 KILOGRAM |
| Indivisible sale quantity | 1 |
